Startseite /Produkte/Saftsterilisationsmaschine/food & Automatic Beverage Factory Glass Bottle Sterilization Machine Factory Made Sterilize Equipment Glass Bottle Sterilizer

food & Automatic Beverage Factory Glass Bottle Sterilization Machine Factory Made Sterilize Equipment Glass Bottle Sterilizer

1 Set
MOQ
$3,000.00(1 - 9 Sets) $1,500.00(10 - 19 Sets) $1,000.00(>=20 Sets)
Preis
food & Automatic Beverage Factory Glass Bottle Sterilization Machine Factory Made Sterilize Equipment Glass Bottle Sterilizer
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Processing: Sterilizer
Applicable Industries: Food & Beverage Factory, Food Shop, Food & Beverage Shops
Showroom Location: Indonesia
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2021
Warranty of core components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear
Condition: New
Model Number: SRD-(1000-10000)
Processing Types: Juice
Voltage: 220V
Power: 2.2KW
Weight: 900 KG
Dimension(L*W*H): 12000*650*1300mm
Warranty: 1 Year
Product Name: Pour bottle sterilizer
Model: SRD-(1000-10000)
Bottle diameter: 50-120
Bottle height: 150-310
Bottle pouring time (s): 30-45
Production capacity(p/h): 15000
Motor power (kw): 2.2
Weight(KG): 900
The main purpose: Glass bottle, PET polyester bottle
Dimensions (mm): 12000*650*1300
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: Indonesia
After-sales Service Provided: Online support
Zertifizierung: CE, ISO9001
Grundinformation
Zertifizierung: CE, ISO9001
Model Number: SRD-(1000-10000), SRD-(1000-10000)
Zahlung und Versand AGB
Packaging Details: 1.Outside Package:standard export wooden case 2.Inside Package: stretch film
Supply Ability: 15 Set/Sets per Month filling capping and labe
Produkt-Beschreibung
Pour bottle sterilizer

This equipment is mainly used to sterilize the parts of the bottle mouth and the inner wall of the bottle cap that have been sterilized or high-temperature treated after hot filling of glass bottles, PET polyester bottles of juice, tea and other beverages. This machine realizes automatic rotation sterilization and self-reset, and during the sterilization process, it is only necessary to sterilize the bottle mouth and the inner wall of the bottle cap through the high temperature of the contents in the bottle.Increase any heat source to achieve energy saving purpose. This machine is mainly composed of a bracket, a vertical bottle conveying device, a horizontal bottle conveying device and a power device. It adopts a mechanical stepless speed change device and the output is adjustable. The frame is made of SUS304 stainless steel. Beautiful shape and convenient operation. The length of the whole machine can be customized according to different requirements of users.
Products Description
Product name
Pour bottle sterilizer
Model
SRD-（1000-10000)
Applicable bottle type (mm)
Bottle diameter: µ50-µ120 Bottle height: 150-310
Bottle pouring time (s)
30-45
Production capacity（p/h）
15000
Motor power (kw)
2.2
Weight（KG）
900
Dimensions(mm)
1100*950*2100MM
Product Information





1、The equipment is mainly used for sterilizing the unsterilized or high-temperature parts of the bottle mouth and the inner wall of the bottle cap after the hot filling of the juice, tea and other drinks packed in glass bottles and PET polyester bottles.





2、The machine realizes automatic reversing sterilization and self-reset, and in the sterilization process, only through the bottle memory of its own high temperature on the bottle mouth and the inner wall of the cap sterilization, without adding any heat source, to achieve the purpose of energy saving.





3、This machine is mainly composed of support, vertical bottle conveying device, horizontal bottle conveying device and power device. It adopts mechanical stepless transmission device, and the output is adjustable.








4、The frame is made of SUS304 stainless steel with beautiful appearance and easy operation. Machine length can be customized according to different requirements of users.
